Manufacturer

Polaris

Model Year

2024

Model

RZR XP 4 1000 Ultimate

Model Code

Z24NMF99AM

Color

Matte Titanium / Onyx Black

Brakes

Front / Rear - 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers

Parking - Park In-Transmission

Front / Rear - 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers

Parking - Park In-Transmission

Wheels

Cast Aluminum

Tires

Trail Master X/T 2.0

Front / Rear - 30 x 10-14 Radial

Trail Master X/T 2.0

Front / Rear - 30 x 10-14 Radial

Length

Overall - 147.8 in. (375.4 cm)

Height

Overall - 75 in. (190.5 cm)

Width

Overall - 64 in. (162.6 cm)

Weight

Estimated Dry - 1,901 lb. (862.3 kg)

Ground Clearance

14 in. (35.6 cm)

Wheelbase

117 in. (297.2 cm)

Transmission

Automatic PVT P / R / N / L / H

Drive System

High Performance True On-Demand AWD / 2WD

Battery

900W Charging System

Instrumentation

RIDE COMMAND 7 in. Glove-Touch Display - Digital Instrumentation, Built-In GPS, Group ride (cell-based or GPS based), Topographic Mapping, Bluetooth and USB Smartphone Connectivity, AM / FM and Weather Radio, In-Vehicle Communications Capable With Optional Sena Headsets Speedometer, Odometer, Tripmeter, Tachometer, Coolant Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light, Fault Code Display, DC Outlet, Ambient Temp Rockford Fosgate® Stage 3 Audio (Including 2 Front and 2 Rear Co-axial Speakers and External 400W Amp), *Group Ride only available in North America

Lighting

LED Head and Tail

Front and Rear LED Accent

Illuminated In-Cab Controls

LED Head and Tail

Front and Rear LED Accent

Illuminated In-Cab Controls

Input

6-Position Pulse Bar

Engine

4-Stroke DOHC

Cooling

Liquid

Cylinders

Twin

Horsepower

114 hp

Displacement

999 cc

Fuel System

Electronic Fuel Injection

Fuel Capacity

9.5 gal. (40 l)

Front Suspension

Dual A-Arm with Stabilizer Bar

Usable Travel - 20.5 in. (52.07 cm)

Wheel Travel - 16 in. (40.6 cm)

Shocks - 2 in. Walker Evans® Needle with 16-Position Adjustable Clickers

Dual A-Arm with Stabilizer Bar

Usable Travel - 20.5 in. (52.07 cm)

Wheel Travel - 16 in. (40.6 cm)

Shocks - 2 in. Walker Evans® Needle with 16-Position Adjustable Clickers

Rear Suspension

Trailing Arm with Stabilizer Bar

Usable Travel - 20.5 in. (52.07 cm)

Wheel Travel - 18 in. (45.7 cm)

Shocks - 2.5 in. Walker Evans® Needle with 16-Position Adjustable Clickers

Trailing Arm with Stabilizer Bar

Usable Travel - 20.5 in. (52.07 cm)

Wheel Travel - 18 in. (45.7 cm)

Shocks - 2.5 in. Walker Evans® Needle with 16-Position Adjustable Clickers

Steering

Tilt

Electronic Power - Standard with Quick Turn Rack

Tilt

Electronic Power - Standard with Quick Turn Rack

Seating

Bolstered Driver and Passenger Bucket seats with Sliders and Subzero Harnesses, *2nd Row Raised Stadium Seating*

Travel Distance

Suspension - usable travel is measured, with the vehicle in full droop, from the bottom of the tire to the bottom of the skid plate.

Additional Colors

Indy Red

Matte Titanium / Onyx Black

Indy Red

Matte Titanium / Onyx Black

Includes

Premium Paint and Graphics, Color Matched Dash and Bumper, Poly Roof

Cargo Box Length

28 in. (72.0 cm)

Cargo Box Height

7 in. (17.8 cm)

Cargo Box Width

22 in. (57.0 cm)

Cargo Box Capacity

300 lb. (136 kg)

Cargo Box

System - Lock & Ride®

Capacity

Payload - 900 lb. (408 kg)

Safety Features

Front and Rear Full Doors, Rear Camera, Subzero Harnesses, Front Tow Loop and Front Bumper
